gSKIN®-XP Heat Flux Sensor

Our gSKIN®-XP heat flux sensor suits most R&D applications. It balances size and sensitivity for a reliable compromise.

With sensing dimensions of 10.0 x 10.0 x 0.5 mm, gSKIN®-XP provides a non-invasive, ultra-high resolution for many thermal optimization, and heat flux sensor R&D processes.

It offers high sensitivity, fast response time, and coheres to ISO 8301. Our gSKIN®-XP has been used in many experimental heat flux measurements, including heat flux sensor battery testing, and heat transfer measurements.

Product Details

  • Low invasiveness and thickness.

  • Ultra-high resolution of thermal energies and temperature differences.

  • All sensors with conductive heat flux calibration support ISO 8301 standards.

  • Models with additional connector purchase are compatible with all gSKIN® DLOG Data Loggers.

    • Please contact us to check whether your current datalogger is compatible with our heat flux sensors.

With your purchase you will receive:

  • 1x gSKIN® -XP sensor
  • 1x connector (if purchased)
  • Calibration Certificate
  • Datalogger Software (if gSKIN® DLOG purchased additionally)

To see all product specifications, please visit our gSKIN® datasheet within our downloads section.

  • Sensing dimensions [mm]: 10.0 x 10.0 x 0.5
  • Max Heat Flux Measurement Range [kW/m2]: 80
  • Sensitivity @22.5 [°C]: 20.0 (typical), 10.0 (min)
  • Response Time [s]: 1.6
  • Operating Temperature Range Max/Min [°C]: -40 to +85
  • Calibration accuracy: ±3%
  • Standard Cable length* [cm]: 100

  • With connector: CHF 489.00

  • Without connector: CHF 479.00

If you are want to purchase in large quantities, please contact us via our contact us form.

The cost of our gSKIN® DLOG datalogger is additional to the sensor purchase. Please visit our shop to see more information on our gSKIN® DLOG datalogger.

532-png-1




Key Downloads

By downloading our gSKIN® Datasheet below, you can access key product specifications.

  • This includes dimensions, cable length, sensitivity, response time, operating temperature ranges, and more information.

By downloading our gSKIN® Product Manual, you will access key product information.

  • This includes a short user guide, installation and maintenance of the sensors, sensor read out processes, and more.

gSKIN® Datasheet
gSKIN® Product Manual

Relevant gSKIN®-XP Applications

Battery Testing and Calorimetry

Explore research papers utilizing our gSKIN®-XP sensors, including research on the Li-ion battery thermal management, thermal runaway prevention, and the degradation in electrochemical capacitors.

Heat Transfer and Flow Measurement

Explore applications using our gSKIN®-XP sensor, including measuring the effects of fuel bed slop and wind on flame spreading, and human heat loss in outdoor settings.

Laser and Energy Applications

Our gSKIN®-XP sensors are used in papers discussing energy applications, including stratified thermal energy storages.

mika-baumeister-USW-dIQpcAk-unsplash
photo-1623265174130-3de7fa152349-1
cemrecan-yurtman-thdb7o0nLyc-unsplash

Interested in discovering our complete range of application areas and featured research papers? Click the "Read more" button below:
